6x41 KENDİR ÖZLÜ ÇELİK HALATLAR
6x41 KENDİR ÖZLÜ ÇELİK HALATLAR
|
6 x 41WS FC6[1+8+(8+8)+16] |
Minimum Kopma Yükü (kN)[Tel Çekme Dayanımına Göre] |
||||
|---|---|---|---|---|---|
|
Halat Çapı (mm) |
Birim Ağırlık (kg/m) |
1570[N/mm2] |
1770[N/mm2] |
1960[N/mm2] |
2160[N/mm2] |
|
12 |
0,529 |
74,6 |
84,1 |
93,1 |
103 |
|
13 |
0,621 |
87,6 |
98,7 |
109 |
120 |
|
14 |
0,720 |
102 |
114 |
127 |
140 |
|
15 |
0,827 |
117 |
131 |
146 |
160 |
|
16 |
0,940 |
133 |
150 |
166 |
182 |
|
17 |
1,062 |
150 |
169 |
187 |
206 |
|
18 |
1,190 |
168 |
189 |
210 |
231 |
|
19 |
1,326 |
187 |
211 |
233 |
257 |
|
20 |
1,469 |
207 |
234 |
259 |
285 |
|
21 |
1,620 |
228 |
258 |
285 |
314 |
|
22 |
1,778 |
251 |
283 |
313 |
345 |
|
23 |
1,943 |
274 |
309 |
342 |
377 |
|
24 |
2,116 |
298 |
336 |
373 |
411 |
|
25 |
2,296 |
324 |
365 |
404 |
446 |
|
26 |
2,483 |
350 |
395 |
437 |
482 |
|
28 |
2,880 |
406 |
458 |
507 |
559 |
|
30 |
3,306 |
466 |
526 |
582 |
642 |
|
32 |
3,762 |
531 |
598 |
662 |
730 |
|
34 |
4,247 |
599 |
675 |
748 |
824 |
|
36 |
4,761 |
671 |
757 |
838 |
924 |
|
38 |
5,305 |
748 |
843 |
934 |
|
|
40 |
5,878 |
829 |
935 |
1.035 |
|
|
42 |
6,480 |
914 |
1.030 |
1.141 |
|
|
44 |
7,112 |
1.003 |
1.131 |
1.252 |
|
|
48 |
8,464 |
1.194 |
1.346 |
1.490 |
|
|
52 |
9,933 |
1.401 |
1.579 |
1.749 |
|
|
56 |
11,520 |
1.625 |
1.832 |
||
|
60 |
13,225 |
1.865 |
2.103 |
||
